Copper pipe/tube
C26000 Brass Pipe/Tube

‹

›

‹

  • C26000 Brass Pipe/Tube
  • C26000 Brass Pipe/Tube
  • C26000 Brass Pipe/Tube
  • C26000 Brass Pipe/Tube
  • C26000 Brass Pipe/Tube

›

C26000 brass pipe, universally known as Cartridge Brass or 70/30 Brass, is a high-ductility alloy consisting of 70% Copper and 30% Zinc. While most commonly associated with ammunition, its "alpha" phase structure makes it the premier choice for tubing that requires severe cold-working, such as complex bending, flaring, or expanding.

Email：sales1@tisco-ssplate.com

Send Now

Description

Applications

HVAC & CoolingAutomotiveMusical InstrumentsSanitary/PlumbingElectronics
Furniture DesignAmmunitionIndustrial Mach.LightingTelecommunications

Specifications Table

Product NameC26000 Cartridge Brass Pipe / Tube
StandardASTM B135, ASTM B587, EN 12449, JIS C2600
Outside Diameter (OD)3 mm - 150 mm
Wall Thickness (WT)0.5 mm - 15 mm
Length2m - 6m (Straight), or Coil
Temper (Hardness)Annealed (O60), 1/4 Hard (H01), 1/2 Hard (H02), Hard (H04)
Surface FinishBright Annealed, Polished, Pickled

Standard Grade Comparison Table

Region / StandardUNS (USA)EN/DIN (Europe)JIS (Japan)GB (China)
Equivalent GradeC26000CW505L / CuZn30C2600H70


Chemical Composition Table (%)

ElementCopper (Cu)Zinc (Zn)Iron (Fe) (Max)Lead (Pb) (Max)
Range68.5 - 71.5Remainder0.050.07


Mechanical Properties Table (Typical for H02 Half-Hard)

PropertyPerformance Data
Tensile Strength (Rm)370 - 460 MPa
Yield Strength (Rp0.2)250 - 380 MPa
Elongation (A50mm)≥15%
Hardness (Rockwell B)55 - 75 HRB


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
