Copper Plate/Sheet
Bronze

‹

›

‹

  • Bronze
  • Bronze
  • Bronze

›

Bronze is one of the oldest and most important alloys in human history. Traditionally, it is a mixture of Copper (typically 88%) and Tin (typically 12%), though modern bronzes often incorporate other elements like aluminum, manganese, silicon, or nickel to achieve specific industrial properties.

Email：sales1@tisco-ssplate.com

Send Now

Description

Applications

Marine EngineeringIndustrial Mach.Art & SculptureElectrical/PowerArchitecture
AerospaceMusical InstrumentsAutomotiveOil & GasMining

Common Industrial Bronze Grades

Bronze TypeCommon GradesKey Alloying ElementsPrimary Characteristics
Tin BronzeC90300, C90500Tin (8%-12%), PhosphorusHigh strength, excellent wear resistance, and great "castability."
Aluminum BronzeC63000, C95400Aluminum (6%-12%), Iron, NickelExtremely high strength and superior corrosion resistance in seawater.
Phosphor BronzeC51000, C54400Tin (4%-9%), Phosphorus (0.5%)Exceptional fatigue resistance and elasticity; the standard for springs.
Silicon BronzeC65500Silicon (3%), ManganeseEasy to weld and highly resistant to fluids; used for architectural hardware.
Manganese BronzeC86300Manganese, Zinc, IronHigh-torque strength; often called "Yellow Bronze."


General Technical Properties

  • Melting Point: 950°C - 1050°C (slightly higher than brass).

  • Density: 7.4 - 8.9 g/cm³ (depending on tin content).

  • Corrosion Resistance: Excellent, particularly against metal-on-metal wear and salt-water corrosion.

  • Mechanical Strength: Generally harder and more brittle than copper, but tougher than most brasses.

  • Non-Sparking: Bronze tools do not strike sparks, making them vital for "ATEX" (explosive atmosphere) zones.


Comparison: Bronze vs. Brass vs. Copper

FeaturePure CopperBrass (Cu+Zn)Bronze (Cu+Sn)
ColorReddish-OrangeBright Yellow/GoldDull Gold/Dark Brown
HardnessSoft/DuctileMediumHigh/Brittle
ConductivityHighestMediumLower
Main UseWiring/ElectronicsDecorative/ValvesBearings/Marine/Springs


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
